Cloud - Bluetooth Active Input Plate for DCM1
SKU: BT-1E
Dispatched today! (Order by 3pm)
The BT-1E is a remote wall-mounting input module for exclusive use with Clouds DCM-1 digital mixers.
A trade-only supplier of installed audio-visual custom technology for resimercial projects.
BT-1E - Bluetooth Wireless Audio Module - Extension Port
The BT-1E is a remote wall-mounting input module for exclusive use with Clouds DCM-1 digital mixers. The BT-1E enables compatible portable devices such as laptops, tablets and smartphones to stream audio wirelessly to the interface, and there into the audio system of the Zone where the interface is installed.
The BT-1E is exceptionally simple to install; the rear RJ45 connector is wired to one of the host unit’s Extension Ports with a single screened Cat 5 cable using standard shielded RJ45 connectors at each end. The Cat 5 cable carries DC power as well as balanced audio.
The BT-1E routes audio in stereo to the host unit and is compatible with the following Cloud products:
- DCM1 Digital Control Zone Mixer.
- DCM1e Ethernet Digital Control Zone Mixer.
Features:
- BT-1EW (White) & BT-1EB (Black).
- Remote Bluetooth input module for Cloud host units with Extension Port Capability.
- Easy connection to host unit via screened Cat 5 cable (up to 100 m).
- Uses single-button Bluetooth “pairing” mode for secured operation.
- Alternative “unsecured” mode: configurable at installation.
- Each module may have one of 16 unique identifiers to differentiate receivers in areas where multiple modules are installed.
- RF power level adjustment to minimise risk of accidental inter-room connection.
- Bicolour LED indicates connection progress and streaming activity.
- May be daisy-chained to remote input modules (e.g., LM-2) in same Zone.
- UK versions mount into a standard single-gang UK-style electrical back box (85 x 85 mm) and require a back box depth of 35 mm minimum.
| Shipping Weight (kg) | 0.170000 |
|---|---|
| Manufacturer | Cloud Electronics |
| Type | Accessory |
