4K up to 40m
The XTND 4K (40m) ARC HDBaseT Lite Extender allows for the reliable extension of 4K@60Hz 4:2:0 content up to 40m and Full HD 1080p up to distances of 70m over a single Cat 6 cable. These distances may be increased using Cat 7 cable and may reduced if using Cat 5e cable. For full cabling and distance specifications, please see the graphic below. HDCP 2.2 compliancy means the XTND 4K (40m) Extenders can be used with the latest 4K HDCP 2.2-encrypted sources and displays.
Bi-directional IR and PoH
Two-way IR allows your client IR control of the extended source device at either the display or the source location. XTND 4K (40m) delivers the HDBaseT Lite 3-Play feature set (UHD/4K/1080p video, multichannel audio and PoH) over a single Cat cable as well as ARC / IR / RS232 / IP control.
Audio Formats
XTND 4K (40m) supports 2.0 channel stereo audio formats, as well as Dolby Digital and DTS 5.1, all 6.1 and 7.1 formats as well as Dolby True HD, DTS Master Audio, Dolby Atmos and DTS:X. ARC is also supported.
In the Box
The XTND 4K (40m) uses lightweight aluminium metalwork with a carbonite colour finish for neater, smarter installation. Power supply and IR gear included.
| Shipping Weight (kg) | 1.000000 |
|---|---|
| Manufacturer | HDANYWHERE |
| Type | Video Extender Kit |
| Product Range | XTND |
| Supported Video Resolution | 4K 60Hz 4:4:4 |
| Distance at Max. Resolution | 40m (4K) |
| Warranty | 1 Year (Return to Base only) |
| Colour | Dark Grey |
| Form Factor | On-Wall |
| Input Types | HDMI, RS232 Phoenix, IR 3.5mm jack |
| Audio Input Types | N/A |
| Supported Outputs | HDMI |
| Maximum Video Inputs | 1 |
| Audio Output Types | S/PDIF |
| Maximum Video Outputs | 1 |
| Supported Audio Formats | Dolby Digital Plus 7.1, Dolby TrueHD 5.1, Dolby TrueHD 7.1, DTS-HD Master 5.1, DTS-HD Master 7.1 |
| HDCP | HDCP 2.2 |
| IR Control | 2-Way |
| HDMI Version | HDMI® 2.0 features supported up to 10.2Gbps |
