MZMA Features:
- The 4-zone matrix amplifier lets you enjoy powerful, high-quality sound from 4 analogue and 2 digital input sources in 4 stereo zones.
- 55W x2 @ 4 Ohms, per zone.
- 3-band EQ - customise the sound in every zone.
- Full matrix switching of 6 x inputs (4 stereo / 2 digital) to 4x zone & slave outputs.
- High-efficiency power supply.
- Auto low power.
- Independent input gain control and volume limiting capabilities.
- Controllable via uControl App (HDA’s universal AV control app) with automatic pairing into one easy to use interface.
MHUB PRO 2.0 (8x8) Features:
- 18G (600MHz) HDMI® 2.0 and HDCP 2.2 compatible.
- Supports source content up to and inc. Ultra HD 4K 60 4:4:4 with High Dynamic Range(HDR) all current formats inc. Dolby Vision®.
- Supports all current audio formats including Dolby Atmos® and DTS:X®.
- HDBaseT 2.0 with PoH.
- Internal video scaling (4K>1080p on every output).
- Internal 20x8 audio matrix switcher with flexible grabbing audio (source or display HDMIARC) via digi coax, or audio downmix via stereo jack.
- Internal uControl IO expander universal controller.
- Control paths via TCP/IP, two-way IR and RS232.
- Backlit fade in/out touch panel controls.
- App/web GUI for easy config (MHUB-OS) with remote management (HDA Cloud).
- 2x integrated 10/100 Ethernet LAN connections at RX.
- Sold as a complete install package, with all receivers, IR cables and mounting kit included.
Note: Using a third-party control system? Purchase as is. Using uControl? Remember to add a Zone Processor.
| Type | Video & Audio Package |
|---|---|
| IO Format | 8x8 |
| Distance at Max. Resolution | 100m (4K) |
| Product Range | MHUB |
| Warranty | 2 years + 3 year with Cloud registration |
| Multiroom Capable | No |
| MSRP | £9,831.67 |
